MIL-PRF-52343 Repair Kit, HoselineThis specification covers a repair kit consisting of tools and materials necessary for temporary and permanent repairs to 4-inch hoselines. The components are contained in a fitted storage chest. The kit is not intended for making repairs to potable water hoseline systems.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


MIL-PRF-52343D
SEE NOTE 2
3X 1.250
3X 0.125
3X 0.250
2X R 0.031
0.500
45° X 0.125
R
4.334
3.750
4.314
4.031
4.531
2X
4.000
4.484
3X 0.078
3X R 0.047
0.625
0.625
0.375
(7.00)
NOTES:
1. Dimensions in inches. Tolerances: .XXX ± .016, ∠ ± 2°
2. Area indicated shall have a matte finish and shall not be sealed after anodizing.
FIGURE 1. Grooved-end to hose adapters ­ example.
