MIL-PRF-52345D
TABLE I. Flow control kit components' list.
Item
Component
Ref.
Quantity
1
Gate valves
3.3.1
2
2
Tee
3.3.2
1
3
Pipe coupling clamp
3.3.3
8
4
Check valves
3.3.4
2
5
Hose assembly
3.3.5
2
6
Strainer assembly
3.3.6
1
7
Grooved-to-external thread coupling
3.3.7
2
8
Grooved-to-internal thread coupling
3.3.8
2
9
Male coupling half
3.3.9
2
10
Female coupling half
3.3.10
2
11
Fish tape
3.3.11
1
3.3.1 Gate valves. The gate valves shall be a 4-inch, rising stem in accordance with
A-A-59379, Type II, except each end of the valve shall be a 4-inch, single grooved end, in
accordance with AWWA C606-97, Table 4 (Cut grooving dimensions - Steel, aluminum, brass,
and other metallic pipe of IPS dimensions).
3.3.2 Tee. The tee shall be aluminum, 4-inch, and grooved at all ends in accordance with
AWWA C606-97, Table 4 (Cut grooving dimensions - Steel, aluminum, brass, and other metallic
pipe of IPS dimensions).
3.3.3 Pipe coupling clamp. The pipe coupling clamps shall be aluminum, 4-inch, in accordance
with A-A-52598.
3.3.4 Check valves. The check valves shall be 4-inch certifiable for a working pressure of 300
pound per square inch (psi). The ends shall be grooved in accordance with AWWA C606-97,
Table 4 (Cut grooving dimensions - Steel, aluminum, brass, and other metallic pipe of IPS
dimensions).
3.3.5 Hose assembly. The hose assembly shall consist of a 60.00-inch long section of 4-inch,
high pressure, non-reinforced, collapsible, lightweight elastomeric tube in accordance with MIL-
PRF-370, with hose coupling adapters secured at each end. The hose adapters shall be single
grooved end, 4-inch I.D., 10.00 inches long, in accordance with AWWA C606-97, Table 4 (Cut
grooving dimensions - Steel, aluminum, brass, and other metallic pipe of IPS dimensions).
3.3.6 Strainer assembly. The strainer assembly shall accept a strainer configuration like that
shown in figure 1, housed in a hose coupling adapter, grooved both ends, 4-inch I.D., 10.00-
inches long, in accordance with AWWA C606-97, Table 4 (Cut grooving dimensions - Steel,
aluminum, brass, and other metallic pipe of IPS dimensions). The strainer shall remove foreign
material .125 ±. .005 inch in diameter and larger. Materials incorporated into the assembly shall
be compatible with all components of the flow control kit. The materials incorporated shall be
capable of meeting all the operational and environmental requirements specified and be reusable
without degradation of performance.
3
