MIL-PRF-52347D
3.3.2.8 Turnbuckles. Turnbuckles shall conform to ASTM F1145, type I, grade 1,
class E.
3.3.2.9 Wire rope thimbles. The wire rope thimbles shall be constructed of cold-rolled or
hot-rolled steel conforming to QQ-S-698 or equivalent strength material. The wire rope thimbles
shall be 0.375 in. size of split oval construction, semi-circular at the closed ends, with the sides
tapering together at the free ends. The free ends shall have a rounded shape. Thimbles shall
conform to the design shown in figure 3.
3.4 Treatment and painting. The portions of the kit normally painted shall be cleaned,
treated, and painted in accordance with the materials being used. Unless otherwise specified
(see 6.2), paint color shall be green 383, number 34094 of FED-STD-195.
FIGURE 3. Wire rope thimble.
3.5 Identification marking. Identification marking shall be permanent and legible and shall
include as a minimum, the manufacturer's name and part number and the National Stock Number
(NSN). Special markings, if any, shall be as specified (see 6.2).
3.6 Workmanship. All components of the kit and chest shall be free of extraneous
material such as sand, dirt, sprues, scale, and flux. External surfaces shall be free from burrs,
sharp edges, and corners.
7
